Views: 13 Author: Site Editor Publish Time: 2025-06-11 Origin: Site
Product features
Equipped with dedicated ES600 hydraulic servo drives and EP series servo motors, it covers a power range of 3.7-160kW and various other specifications.
By detecting the real-time motor speed through encoder line, speed closed-loop control is achieved. Real-time pressure sensing via pressure sensors enables pressure closed-loop control of the system, ultimately achieving dual-loop control of hydraulic flow and pressure. Energy consumption is reduced by 30-60%. Under equivalent conditions, oil temperature decreases by 5-10°C. After complete station transformation, noise is reduced by 5-10DB. Only the motor is replaced, with no modifications to the hydraulic system. Motor oiling is reduced, leading to decreased maintenance. The system can operate continuously at high speed at 40°C for 6-8 years. The overall construction process takes a minimum of one day and does not require shutdown, thus not affecting production.
25MPa system pressure hydraulic station servo complete configuration table
Pressure | Oil pump displacement | Motor | Servo drive | ||
cc | Model | Model | Parameter | Model | Parameter |
25 | 20 | EP18-66F17K | 64Nm,1700rpm | ES600T025 | 11KW |
25 | 25 | EP18-70F17K | 70Nm,1700rpm | ES600T032 | 15kw |
25 | 32 | EP18-95F17K | 120Nm,1700rpm | ES600T037 | 18.5kw |
25 | 40 | EP18-120F17K | 120Nm,1700rpm | ES600T045 | 22KW |
25 | 50 | EP18-153F17K | 150Nm,1700rpm | ES600T060 | 30KW |
25 | 63 | EP18-168F17K | 171Nm,1700rpm | ES600T075 | 37KW |
25 | 80 | EP25-286F17K | 280Nm,1700rpm | ES600T091 | 55KW |
25 | 100 | EP25-340F17K | 340Nm,1700rpm | ES600T112 | 55KW |
25 | 125 | EP25-388F17K | 380Nm,1700rpm | ES600T150 | 75KW |
25 | 160 | EP25-504F17K | 500Nm,1700rpm | ES600T175 | 90KW |
17.5MPa system pressure hydraulic station servo complete configuration table
Pressure | Oil pump displacement | Motor | Servo drive | ||
cc | Model | Model | Parameter | Model | Parameter |
25 | 20 | EP18-40F17K | 42Nm,1700rpm | ES600T017 | 7.5KW |
25 | 25 | EP18-66F17K | 64Nm,1700rpm | ES600T025 | 11kw |
25 | 32 | EP18-70F17K | 70Nm,1700rpm | ES600T032 | 15kw |
25 | 40 | EP18-88F17K | 86Nm,1700rpm | ES600T032 | 15KW |
25 | 50 | EP18-105F17K | 107Nm,1700rpm | ES600T037 | 18.5KW |
25 | 63 | EP18-131F17K | 129Nm,1700rpm | ES600T045 | 22KW |
25 | 80 | EP18-168F17K | 171Nm,1700rpm | ES600T075 | 37KW |
25 | 100 | EP25-236F17K | 220Nm,1700rpm | ES600T091 | 45KW |
25 | 125 | EP25-286F17K | 280Nm,1700rpm | ES600T112 | 55KW |
25 | 160 | EP25-344F17K | 340Nm,1700rpm | ES600T150 | 75KW |
 |  |
