Product features

Traditional hydraulic presses use ordinary asynchronous motors, which are bulky and occupy a lot of space. Moreover, their non-stop operation leads to overall high oil temperatures, necessitating a correspondingly large oil tank volume. In contrast, the electro-hydraulic servo system adopts an intelligent servo energy-saving system, reducing power consumption by 30%-50%. Each machine is equipped with an infrared grating, which effectively protects operators. It can achieve pressure control accuracy of up to 1bar and position control accuracy of 0.05mm on different types of hydraulic press equipment. The system supports various pressing modes (such as sheet stamping, drawing, resistance to drawing, precision stamping), ensuring the machine's repeat positioning accuracy of up to ±0.05mm and pressure error within ±1%. The servo intelligent control system operates efficiently, preventing unnecessary work and minimizing oil temperature increase. Additionally, the absence of negative pressure within the oil circuit system significantly reduces the failure rate, prolonging the lifespan of hydraulic components. The electrical equipment is equipped with automatic fault alarms and a one-click reset function. Currently, it serves numerous large oil pressure equipment manufacturers and users worldwide, receiving unanimous recognition within the industry.

25MPa hydraulic press pump complete servo system configuration table
